C++: Embedding the V8 JavaScript Engine

V8 is Chromium’s JavaScript interpreter. Not only can you use the included D8 utility to open a console and execute JavaScript code directly, but it is not as tough as you would think to integrate your native functions from your JavaScript and your JavaScript functions from your native functions. Of course, you have to get your head around all of the layers of isolates, context, and scoping.

For a walkthrough of embedding V8, start here.

In order to build a quick example of how to implement a native function for consumption from your JavaScript, go ahead and build V8. You will have to choose how to build the project. You’ll provide the name of a particular build configuration, which will write a few build parameters (called “args”) to the “out.gn//args.gn” file. This is a GN thing. GN is a build tool from the Chromium depot-tools project that generates Ninja scripts for doing the actual build.

For a list of build configurations, run:

$ tools/dev/v8gen.py list
...
s390.optdebug
s390.optdebug.sim
s390.release
s390.release.sim
s390x.debug
s390x.debug.sim
s390x.optdebug
s390x.optdebug.sim
s390x.release
s390x.release.sim
x64.debug
x64.optdebug
x64.release
x64.release.sample

(list shortened for simplicity)

We’ve used the “x64.release.sample” configuration for our example. It is straightforward for the purpose of this example. Once you have V8 downloaded and the dependencies installed, the actual project builds in about fifteen-minutes (with sixteen threads).

Drop this example into a file named “native_function.cpp” (or update the build command below to whatever you go with). This is an amalgam of excerpts from the samples in the project, examples in the documentation, and some customization on our part.

#include <sstream>

#include "libplatform/libplatform.h"
#include "v8.h"

// This is the function that we'll register into JS as a global function.
static void TestCallback(const v8::FunctionCallbackInfo<v8::Value>& args) {
  v8::Isolate* isolate = args.GetIsolate();
  v8::HandleScope scope(isolate);

  // Return [the arbitrary integer] 55 as our result.
  auto result = v8::Integer::New(isolate, 55);

  // Set the result.
  args.GetReturnValue().Set(result);
}

int main(int argc, char* argv[]) {

  // Initialize V8.
  v8::V8::InitializeICUDefaultLocation(argv[0]);
  v8::V8::InitializeExternalStartupData(argv[0]);
  std::unique_ptr<v8::Platform> platform = v8::platform::NewDefaultPlatform();
  v8::V8::InitializePlatform(platform.get());
  v8::V8::Initialize();

  // Create a new Isolate and make it the current one.
  v8::Isolate::CreateParams create_params;
  create_params.array_buffer_allocator =
      v8::ArrayBuffer::Allocator::NewDefaultAllocator();

  v8::Isolate* isolate = v8::Isolate::New(create_params);

  // Scoping in the C++ is tightly related to scoping in the JS. So, we'll
  // retain the organizational blocks from the samples.
  {
    v8::Isolate::Scope isolate_scope(isolate);

    // Create a stack-allocated handle scope.
    v8::HandleScope handle_scope(isolate);

    // Create a global object to install our function into.
    v8::Local<v8::ObjectTemplate> global = v8::ObjectTemplate::New(isolate);

    // Register our global function.
    global->Set(
      v8::String::NewFromUtf8(isolate, "testCall", v8::NewStringType::kNormal).ToLocalChecked(),
      v8::FunctionTemplate::New(isolate, TestCallback)
    );

    // Create a new context and apply the global object.
    v8::Local<v8::Context> context = v8::Context::New(isolate, NULL, global);

    // Enter the context for compiling and running the hello world script.
    v8::Context::Scope context_scope(context);

    // Load the script.

    std::stringstream sourceStream;

    sourceStream
      << "testCall();" << std::endl;

    v8::Local<v8::String> source =
      v8::String::NewFromUtf8(
          isolate,
          sourceStream.str().c_str(),
          v8::NewStringType::kNormal)
        .ToLocalChecked();

    // Compile the source code.
    v8::Local<v8::Script> script =
      v8::Script::Compile(context, source)
        .ToLocalChecked();

    // Run the script.
    v8::Local<v8::Value> result = script->Run(context).ToLocalChecked();

    // Print the screen output.
    v8::String::Utf8Value output(isolate, result);
    printf("%s\n", *output);
  }

  // Dispose the isolate and tear down V8.
  isolate->Dispose();
  v8::V8::Dispose();
  v8::V8::ShutdownPlatform();
  delete create_params.array_buffer_allocator;

  return 0;
}

To build, set V8PATH to the absolute path of your “v8/v8” directory (the main V8 path established in the getting-started document above), and run the following:

$ g++ "-I${V8PATH}/include" -o native_function native_function.cpp -lv8_monolith "-L${V8PATH}/out.gn/x64.release.sample/obj" -pthread -std=c++0x

The example implements a simple, native function that just returns (55), registers it as a global JS function, creates a simple JS script that calls it, and then runs the script and prints the screen output. The screen output is just the result of that function printed to the screen since it was not otherwise assigned to a variable:

$ ./native_function
55

For a couple of more examples, see the project repository.

Advertisements

Go: Read and Browse Ext4 Filesystems in User-Space

go-ext4 is a pure Go implementation of an Ext4 reader with support for reading the journal. An example of how to walk the file-structure:

inodeNumber := InodeRootDirectory

filepath := path.Join(assetsPath, "hierarchy_32.ext4")

f, err := os.Open(filepath)
log.PanicIf(err)

defer f.Close()

_, err = f.Seek(Superblock0Offset, io.SeekStart)
log.PanicIf(err)

sb, err := NewSuperblockWithReader(f)
log.PanicIf(err)

bgdl, err := NewBlockGroupDescriptorListWithReadSeeker(f, sb)
log.PanicIf(err)

bgd, err := bgdl.GetWithAbsoluteInode(inodeNumber)
log.PanicIf(err)

dw, err := NewDirectoryWalk(f, bgd, inodeNumber)
log.PanicIf(err)

allEntries := make([]string, 0)

for {
    fullPath, de, err := dw.Next()
    if err == io.EOF {
        break
    } else if err != nil {
        log.Panic(err)
    }

    description := fmt.Sprintf("%s: %s", fullPath, de.String())
    allEntries = append(allEntries, description)
}

sort.Strings(allEntries)

for _, entryDescription := range allEntries {
    fmt.Println(entryDescription)
}

// Output:
//
// directory1/fortune1: DirectoryEntry
// directory1/fortune2: DirectoryEntry
// directory1/fortune5: DirectoryEntry
// directory1/fortune6: DirectoryEntry
// directory1/subdirectory1/fortune3: DirectoryEntry
// directory1/subdirectory1/fortune4: DirectoryEntry
// directory1/subdirectory1: DirectoryEntry
// directory1/subdirectory2/fortune7: DirectoryEntry
// directory1/subdirectory2/fortune8: DirectoryEntry
// directory1/subdirectory2: DirectoryEntry
// directory1: DirectoryEntry
// directory2/fortune10: DirectoryEntry
// directory2/fortune9: DirectoryEntry
// directory2: DirectoryEntry
// lost+found: DirectoryEntry
// thejungle.txt: DirectoryEntry

This project is used to directly read the filesystem, file, and journal data without the support of kernel or the FUSE interface. Therefore, no elevated privileges are required.

Python: Retrieve User Info from LDAP

Supports returning the full DN for the user as well as a list of groups that they are a member of:

import logging
import ldap
import collections

# Install:
#
# apt: libsasl2-dev
# pip: python-ldap
#

_USER_QUERY = '(&(objectClass=USER)(sAMAccountName={username}))'
_GROUP_QUERY = '(&(objectClass=GROUP)(cn={group_name}))'

_LOGGER = logging.getLogger(__name__)

_USER = \
    collections.namedtuple(
        '_USER', [
            'dn',
            'attributes',
            'groups',
        ])


class NotFoundException(Exception):
    pass


class LdapAdapter(object):
    def __init__(self, host_and_port, username, password, base_dn):
        self.__host_and_port = host_and_port
        self.__username = username
        self.__password = password
        self.__base_dn = base_dn

        self.__raw_resource = None

    @property
    def __resource(self):
        if self.__raw_resource is None:
            self.__raw_resource = self.__auth()

        return self.__raw_resource

    def __auth(self):
        conn = ldap.initialize('ldap://' + self.__host_and_port)
        conn.protocol_version = 3
        conn.set_option(ldap.OPT_REFERRALS, 0)

        try:
            conn.simple_bind_s(self.__username, self.__password)
        except ldap.INVALID_CREDENTIALS:
            # Pinned, for the future.

            raise
        except ldap.SERVER_DOWN:
            # Pinned, for the future.

            raise
        except ldap.LDAPError:
            _LOGGER.error("LDAP error content:\n{}".format(e.message))

            if issubclass(e.message.__class__, dict) is True and \
               'desc' in e.message:
                raise Exception("LDAP: {}".format(e.message['desc']))

            raise
        else:
            return conn

    def get_dn_by_username(self, username):
        """Return user information. See _USER."""

        uf = _USER_QUERY.format(username=username)
        results_raw = \
            self.__resource.search_s(
                self.__base_dn,
                ldap.SCOPE_SUBTREE,
                uf)

        if not results_raw:
            raise NotFoundException(username)

        results = []
        for dn, attributes in results_raw:
            if dn is None:
                continue

            u = _USER(
                    dn=dn,
                    attributes=attributes,
                    groups=attributes['memberOf'])

            results.append(u)

        assert \
            len(results) == 1, \
            "More than one result was found for user [{}], which doesn't " \
            "make sense: {}".format(username, results)

        return results[0]

    def get_group_members(self, group_name):
        """Return a list of DNs."""

        gf = _GROUP_QUERY.format(group_name=group_name)
        results_raw = \
            self.__resource.search_s(
                self.__base_dn,
                ldap.SCOPE_SUBTREE,
                gf)

        if not results_raw:
            raise NotFoundException(group_name)

        collections = []
        for dn, attributes in results_raw:
            if dn is None:
                continue

            collections.append(attributes['member'])

        if not collections:
            raise NotFoundException(group_name)

        assert \
            len(collections) == 1, \
            "Too many sets of results returned: {}".format(collections)

        return collections[0]

Go: Implementing Subcommands With go-flags

github.com/jessevdk/go-flags is the go-to tool for argument processing. It supports subcommands but understanding how to do it is a feat of reverse-engineering. So, here is an example.

Code:

package main

import (
    "os"

    "github.com/jessevdk/go-flags"
)

type readParameters struct {
}

type writeParameters struct {
}

type parameters struct {
    Verbose bool `short:"v" long:"verbose" description:"Display logging"`
    Read readParameters `command:"read" alias:"r" description:"Read functions"`
    Write readParameters `command:"write" alias:"w" description:"Write functions"`
}

var (
    arguments = new(parameters)
)

func main() {
    p := flags.NewParser(arguments, flags.Default)

    _, err := p.Parse()
    if err != nil {
        os.Exit(-1)
    }

    switch p.Active.Name {
    case "read":
        //...
    case "write":
        //...
    }
}

If you were to save it as "args.go", this is what the help and the usage would look like:

$ go run args.go -h
Usage:
  args [OPTIONS]

Application Options:
  -v, --verbose  Display logging

Help Options:
  -h, --help     Show this help message

Available commands:
  read   Read functions (aliases: r)
  write  Write functions (aliases: w)

exit status 255

$ go run args.go read

Ridiculously Simple Google Hash Function

A Go implementation based on the paper “A Fast, Minimal Memory, Consistent Hash Algorithm”, describing an evenly distributed hashing function called the “Jump” algorithm:

func Hash(key uint64, numBuckets int) int32 {
    var b int64 = -1
    var j int64

    for j < int64(numBuckets) {
        b = j
        key = key*2862933555777941757 + 1
        j = int64(float64(b+1) * (float64(int64(1)<<31) / float64((key>>33)+1)))
    }

    return int32(b)
}

If you’re curious about that constant, it is “known to produce a good random number list” for 64-bit generators:

MSBuild/C#: How to Manage the Application Version Using a Text-File

Overview

C# applications have an “AssemblyInfo.cs” file that describe the assembly and executable versions of a project. Unfortunately, sometimes it is not possible to access this from the code. Other times, you need to drive this version from external sources (like a build system) and then use it for the build.

The approach this by keeping the version in a text-file:

  1. Manually set/update the version in a text-file.
  2. Install a package that helps us with string-replacements.
  3. Inject this to AssemblyInfo.cs during the build.
  4. Embed this file into the executing assembly.
  5. Extract this file file the executing assembly when you need to know it during execution.

The title of this post is a simplification for lack of an easy way to succinctly describe five steps in a couple of words.

Do It

Feel free to modify/customize these steps as suits your needs.

1. Create the Version File

Create a file called “executable.version” in the “Properties\” folder of your executable project. Make sure to include this in your project. In the “Properties” window, set “Build Action” to “Embedded Resource”.

2. Install the “MSBuild Community Tasks” NuGet Package

This is the “MSBuildTasks” package. This provides us a regular-expression string-replacement MSBuild task.

3. Create a template “AssemblyVersion.cs” File

Copy “Properties\AssemblyInfo.cs” to “Properties\AssemblyInfo.cs.use_this” and update the two version attributes as the bottom to be the following:

[assembly: AssemblyVersion("__EXECUTABLE_VERSION__")]
[assembly: AssemblyFileVersion("__EXECUTABLE_VERSION__")]

Make sure to include this new file in the project. Note that we name this so as to not have the “.cs” extension because, otherwise, Visual Studio will try to parse it and complain about the attributes being duplicated from the “AssemblyInfo.cs” file.

4. Add the Build Step

We are going to add a custom build target to inject the version. We personally chose to put this into a separate rules file in order to make it clear which of the build-logic was ours, but this is up to you. It would just as easily work if it were included at the bottom of your project-file. Create “Properties\build.targets” with the following:

(build.targets)

<?xml version="1.0" encoding="utf-8" ?>
<Project ToolsVersion="12.0" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

<!-- Inject a version from a text-file into AssemblyVersion.cs . We do this
 so that it's easier for the application to know its own version [by
 reading the text file].
 -->
 <Import Project="$(ProjectDir)..\packages\MSBuildTasks.1.5.0.196\tools\MSBuild.Community.Tasks.Targets" />
 <Target Name="InjectVersion" BeforeTargets="BeforeBuild">
 <!-- Read the version from our text file. This appears to automatically
 trim (probably per line). This is located in the project root so
 that we copy the file to the output-path rather than establishing
 a whole Properties/ directory in the output path.
 -->
 <ReadLinesFromFile File="$(ProjectDir)Properties\executable.version">
 <Output TaskParameter="Lines" PropertyName="ExecutableVersion" />
 </ReadLinesFromFile>

<!-- Print it to the build output whether we're in debug-mode or not. -->
 <Message Importance="High" Text="Executable version is [$(ExecutableVersion)]"/>

<!-- Copy our template file to the output file. -->
 <Copy SourceFiles="$(ProjectDir)Properties/AssemblyInfo.cs.use_this" DestinationFiles="$(ProjectDir)Properties/AssemblyInfo.cs"/>

<!-- Do an RX replace of the version on to the token. -->

<ItemGroup>
 <WriteFiles Include='$(ProjectDir)Properties/AssemblyInfo.cs' />
 </ItemGroup>

<FileUpdate
 Files="@(WriteFiles)"
 Regex="__EXECUTABLE_VERSION__"
 ReplacementText="$(ExecutableVersion)"
 />

<!-- Replace the cautionary note about how to use the file with one
 saying that any changes will be lost (if made to the output file).
 -->
 <FileUpdate
 Files="@(WriteFiles)"
 Regex="// TEMPLATE:.+"
 ReplacementText="// THIS FILE IS GENERATED! Apply any changes to 'AssemblyInfo.cs.use_this', instead."
 />
 </Target>
</Project>

IMPORTANT: Notice that we have to import the build targets provided by the “MSBuildTasks” package:

$(ProjectDir)..\packages\MSBuildTasks.1.5.0.196\tools\MSBuild.Community.Tasks.Targets

For us, NuGet packages go into the “packages” directory that is in the parent directory of our project directory. Also notice that we have to embed the version for this NuGet package. If your package is a different version or is located in a different place, you will have to update the example to be accurate.

NOTE: One way to get around having to embed the version is to bypass putting this package in your “packages.config file” and, instead, do a manual NuGet install of this package from a build-task to your packages directory (whereever it is) while also passing the “-ExcludeVersion” argument so as to not put the version in the package’s directory name.

Now, import the “build.targets” file from your project file. Put it somewhere near the bottom. Since it will run before the “BeforeBuild” target, we put it before that (which will be commented-out unless you use it):

 <Import Project="$(MSBuildToolsPath)\Microsoft.CSharp.targets" />
 <Import Project="Properties\build.targets" />

5. Reading the Version From the Application

At this point, you should be able to build your project. The only thing that might be considered a disadvantage to this method is that, every time you build your project from inside Visual Studio, you will be prompted to reload the “AssemblyInfo.cs” file because it has been updated from outside of VS even if it has not changed (which is no stupider than the amount of work that we are required to do in order to find our own version). It would be easiest to check the box in this popup that says to only tell you if you happen to have unsaved changes to a file that has been changed from outside VS.

In our case, we are using the CLAP command-line parser. So, we added a private “ExecutableVersion” getter on the class that we are using to handle our subcommands. Then, we added a “version” subcommand that reads and prints the new property. Code for the property:

(Program.cs)

private string executableVersion = null;

private string ExecutableVersion
{
    get
    {
        if (executableVersion == null)
        {
            Assembly assembly = Assembly.GetExecutingAssembly();
            string assemblyName = assembly.GetName().Name;

            // "Properties" is required since it is located in the
            // Properties folder of the project and was thusly embedded
            // as such.
            string filepath = assemblyName + @".Properties.executable.version";

            string[] names = assembly.GetManifestResourceNames();
            var stream = assembly.GetManifestResourceStream(filepath);
            if (stream == null)
            {
                throw new Exception(String.Format("Could not get resource-stream with name [{0}] for version content from assembly [{1}]. Available: {2}", filepath, assembly.FullName, String.Join(",", names)));
            }

            TextReader tr = new StreamReader(stream);
            executableVersion = tr.ReadToEnd().Trim();
        }

        return executableVersion;
    }
}
